Description
The Lab Evaporator set-up pilot plant facility is a versatile and compact solution for conducting distillation trials on various heat-sensitive products. The set-up consists of an SPDU (Short Path Distillation Unit) with a surface area of 0.02 m2, a cold trap, a feeding arrangement, and glass receivers for the distillate and concentrate. It occupies minimal space, making it suitable for use in a variety of settings
Plant Details
Features
Applications
Product specifications
Plant Details
The pilot plant is capable of processing a feed rate of 1-2 liters per hour, and it can be heated by either thermic fluid or steam up to 300°C. Additionally, it can achieve pressures as low as 0.001 mbar, which is ideal for working with heat-sensitive products. The low residence time and single-pass distillation design of the SPDU ensure efficient and effective distillation.
One of the main advantages of taking a trial of our pilot plant is the ability to test and optimize the distillation process for a specific product before committing to a large-scale installation. This can save time and money by identifying potential issues early on and making necessary adjustments before scaling up.
To take advantage of the Lab Evaporator set-up pilot plant, you can hire the set-up on a rental basis. This allows you to test the pilot plant at your own facility and get hands-on experience with the equipment. This gives you an opportunity to understand the technology and process before making a decision to buy.
In terms of installation, the Lab Evaporator set-up pilot plant is easy to install, commission and operate. The equipment is fully tested before delivery, and our engineers will be available to provide installation, commissioning, and training support as required.
The filters are available in various sizes (with filtering surface areas from 20 to 170 m2) and they can be customized to suit the needs of a particular client.
Features
- Occupies just 0.02 m2 area
- Suitable for a feed rate of 1-2 lit/hr
- Heating by thermic fluid or steam up to 300°C
- Achievable pressure down to 0.001 mbar
- Very low residence time
- Required distillation achieved in a single pass
- Suitable heat sensitive product
Applications
This pilot plant has a wide range of applications, including:
- Essential oil distillation
- Flavors and fragrances distillation
- CBD oil distillation
- Botanical extracts distillation
- Pharmaceutical distillation
- Biotech distillation
The Lab Evaporator set-up pilot plant is a compact, efficient, and versatile solution for conducting distillation trials on heat-sensitive products. Taking a trial of the pilot plant allows you to test and optimize the distillation process for a specific product before committing to a larger-scale installation, saving time and money in the long run. You can also hire the set-up on a rental basis, and it comes with easy installation and commissioning support.
Product specifications
CFK-N find applications in:
- Winemaking
